MEMS test equipment standardization: A path to efficiency and cost reduction

After more than two decades of MEMS industrialization, the time is ripe for transitioning to standardized testing equipment and methodologies, leaving behind the era of custom, application-specific solutions. This shift promises significant improvements in efficiency, cost-effectiveness, and scalability for MEMS manufacturers navigating an increasingly competitive landscape.

The challenge of MEMS testing

Since the turn of the century, MEMS devices have found applications in everything from consumer electronics (smartphones, wearables) to automotive systems (inertial measurement units for safety, pressure sensors for tires) and healthcare devices (glucose monitors, implantable sensors).

However, as demand skyrocketed, manufacturers faced a dual challenge: delivering high-performance devices while grappling with shrinking profit margins due to reductions in average selling prices.

Key strategies to maintain profitability in this scenario include:

• Achieving high production yields (>95%)
• Establishing standardized manufacturing and testing approaches
• Outsourcing assembly and test processes to specialized providers

Among these, testing and calibration represent significant cost contributors, often accounting for a substantial portion of the overall manufacturing expenses. For instance, complex MEMS devices requiring intricate physical stimuli and precise measurements can see testing costs ranging from 15% to 30% of the total production cost.

This makes testing a crucial focal point for improvement. Despite technological advancements, challenges related to calibration and accuracy remain, potentially hindering the MEMS market’s full growth potential.

The intricate design and sensitive nature of MEMS devices pose unique challenges when it comes to testing. Unlike traditional integrated circuits that primarily deal with electrical signals, MEMS devices often involve complex structures and interactions between mechanical, electrical, optical, thermal, and chemical components, requiring precise control and measurement across multiple domains.

Consider a MEMS accelerometer: its functionality relies on the movement of a microscopic mass in response to acceleration, which then translates into an electrical signal. Testing this device requires not only electrical measurements but also the application of precisely controlled mechanical stimuli.

Similarly, a pressure sensor needs accurate pressure application and measurement, while a gyroscope requires controlled angular motion. As they work as interfaces into the physical world, traditional electrical testing is not enough to capture their mechanical aspects.

The key thing about their testing is giving physical stimulus into the devices, in order to activate the transducer inside them: The input is run through a transducer to convert into an electrical signal, which can then be processed.

The reliance on custom-built test solutions further exacerbates these challenges. Developing bespoke equipment for each specific MEMS device can lead to longer development cycles for new products, as each test setup needs to be designed, built, and validated from scratch.

Furthermore, these custom solutions often lack scalability, making it difficult and costly to ramp up production volumes. Integrating custom equipment with other manufacturing systems and data analysis tools can also be a complex and time-consuming process.

Moreover, maintaining and upgrading custom equipment often requires specialized expertise, leading to higher operational costs and potential production bottlenecks if the necessary expertise is not readily available.

The need for MEMS test equipment standardization

Testing plays a critical role in semiconductor manufacturing efficiency, directly influencing the final product’s cost. This is particularly pronounced for MEMS devices, where custom test equipment has traditionally been designed for specific applications, rendering it unsuitable for other types of MEMS.

For years, manufacturers and test equipment suppliers have developed bespoke solutions for each device, whether pressure sensors, accelerometers, or microphones. However, this approach based on custom-built setups has limitations in terms of efficiency, cost-effectiveness, and scalability.

Custom-built test setups can be expensive to develop and maintain, especially for low-volume production. Additionally, they often lack the flexibility to adapt to evolving testing requirements or new product variations without significant redesign.

The industry is now recognizing the need for a shift towards standardized, scalable and modular test equipment solutions that can accommodate various MEMS technologies on high-volume production lines.

This need is further amplified by the increasing complexity of modern MEMS devices, such as multi-sensor fusion devices that integrate several sensing elements into a single chip, requiring comprehensive and adaptable testing methodologies.

Benefits of standardized MEMS test equipment

A modern MEMS test setup includes a handler, test resources, and an interchangeable test unit that stimulates the device during electrical testing. What sets standardized solutions apart is their flexibility—a single test cell can be adapted to test various MEMS devices by simply swapping out the test unit. This modularity is achieved through common hardware and software architectures that allow for the integration of different test modules tailored to specific MEMS families.

This approach offers several key benefits:

• Reusability across applications: Standardized equipment, built on a common platform, can be applied across multiple MEMS devices, eliminating the need for a unique machine for each product. For example, the same base ATE system and test handler can be used to test accelerometers, gyroscopes, and pressure sensors by simply changing the specific test unit that provides the necessary physical stimulus and measurement capabilities for each device type. This reusability significantly reduces the overall capital expenditure on test equipment.
• Higher efficiency: A unified test setup reduces downtime and maximizes uptime, making it an ideal solution for high-volume production lines. Standardized platforms often feature optimized test sequences and parallel testing capabilities, which can significantly reduce the overall test time per device. Furthermore, the ease of switching between test units (typically within hours) minimizes production interruptions when transitioning between different MEMS products. Standardized maintenance procedures and readily available spare parts also contribute to reduced downtime and increased overall equipment efficiency.
• Scalability: The same base equipment can be scaled from engineering and mid-volume production to mass production by adding or modifying test modules as needed. For instance, a manufacturer might start with a single test cell for initial product development and then easily add more test cells to the same standardized platform as production volumes increase. This scalability allows companies to adapt to changing market demands without requiring significant new investments in entirely different test systems. The modular design also allows for incremental upgrades and expansions of the test capabilities as needed.
• Cost reduction: The ability to reuse test handlers and replace only specific test units cuts down on equipment costs. Instead of investing in completely new test systems for each MEMS device, manufacturers can leverage their existing standardized platform and only purchase the necessary test units, leading to significant savings in capital expenditure. Moreover, the standardized approach leads to faster time-to-market for new products by reducing the time required to develop and deploy new test solutions. Lower maintenance and training costs associated with a common platform further contribute to the overall cost reduction.

A standard ATE architecture for MEMS

The standardized Automatic Test Equipment (ATE) architecture is built for flexibility and scalability. It comprises modular test units that can be interchanged depending on the MEMS technology being tested. The downtime for switching between test units and products is minimal—typically under 4 hours—ensuring minimal disruption to production.

Key components of a typical MEMS test cell include:

• High-throughput test handler: This system is designed to automatically move MEMS devices through the testing process. For delicate MEMS devices, these handlers incorporate features like precision robotic arms, specialized pickup mechanisms, and controlled movement to ensure gentle handling without applying excessive force that would interfere with the devices working. High-speed movement capabilities are also crucial for maximizing throughput in high-volume manufacturing environments.
• High-performance test resources: These are the core measurement instruments within the test cell, providing advanced measurement capabilities and accuracy across various electrical parameters (voltage, current, resistance, capacitance, etc.). They also include sophisticated timing and frequency measurement capabilities for dynamic testing of MEMS devices. Advanced signal processing capabilities are essential for analyzing the often complex output signals from MEMS sensors.
• Test units able to apply various physical stimuli: These modular units are the key to adapting the standardized ATE for different MEMS technologies. They are designed to precisely generate and control various physical stimuli, including:
  • Acceleration: Achieved using highly accurate rate tables or shakers with precise control over acceleration levels and frequencies.
  • Angular stimuli: Generated using rate tables with precise control over angular velocity and position, crucial for testing gyroscopes.
  • Vibration (high g acceleration): Produced by vibration generators (“shakers”) with controlled frequency and amplitude, essential for testing high g accelerometers used in automotive airbag applications.
  • Acoustic stimuli: Generated by calibrated sound sources and artificial ears with precise control over frequency and sound pressure levels, vital for testing microphones, speakers and acoustic sensors
  • Pressure: Applied using highly accurate pressure generators and measurement systems, crucial for testing a variety of pressure and environmental sensors, including barometric sensors and tire pressure monitoring sensors (TPMS).
  • Magnetic field: Generated by magneto boards with controlled field strength and orientation, necessary for testing geomagnetic sensors and speed sensors.
  • Humidity and gas: Controlled using environmental chambers with precise regulation of humidity levels and gas concentrations, important for testing environmental sensors. These test units also incorporate mechanisms for isolating the devices from unwanted environmental influences, ensuring the accuracy and repeatability of the test results.
• Thermal conditioning: This subsystem provides precise temperature control to perform tri-temp testing (cold/ambient/hot). Testing MEMS devices across a range of temperatures is crucial for characterizing their performance and ensuring reliability under different operating conditions. Advanced thermal control units ensure accurate and stable temperature conditions during testing.
• Contacting units (sockets and probes): These components provide the interface between the test equipment and the MEMS device under test. They are designed to gently contact the delicate MEMS devices, ensuring reliable electrical connections without affecting their mechanical behavior. Specialized socket designs and probe cards are used to accommodate different MEMS package types and pin configurations.

By using standard ATE, companies can achieve:

• 100% uptime: With reconfigurable test units, production runs continuously with minimal downtime for equipment changes or maintenance.
• Test unit modularity: Test units can be tailored for different MEMS families, including accelerometers, gyroscopes, microphones, and magnetic sensors, among others.
• Rapid product switchover: The modular design allows for quick changes between test units, ensuring maximum flexibility and efficient utilization of the test equipment.

The future of MEMS testing

The future of MEMS testing lies in standardization. Standardized test handlers and testers, built on a common platform and equipped with modular, interchangeable units, offer manufacturers the flexibility they need to test a broad array of devices with minimal downtime and maximum efficiency.

This not only lowers costs but also allows companies to keep pace with the increasing complexity and volume of MEMS devices. Emerging trends in MEMS technology, such as the development of smaller, more integrated, and multi-functional sensors, will further drive the need for adaptable and standardized testing solutions.

The integration of software and data analytics into standardized test platforms will also play a crucial role in optimizing test processes, improving yield, and enabling predictive maintenance. Furthermore, the potential of AI and machine learning to automate test program generation and fault diagnosis could revolutionize MEMS testing in the years to come.

Transitioning to standardized testing: Practical considerations

While the benefits of standardized MEMS testing are clear, the transition from custom solutions requires careful planning and consideration. Manufacturers might have initial concerns about the investment costs associated with new equipment and the potential learning curve for their engineering and production teams.

It’s important to evaluate the long-term cost savings and efficiency gains that standardized equipment offers.

When selecting a standardized test equipment provider, manufacturers should consider factors such as the range of MEMS devices the platform can support, the required test capabilities and accuracy levels, the throughput requirements for their production volumes, the total cost of ownership (including maintenance and support), and the reputation and reliability of the supplier.

Thorough evaluation and a phased approach to implementation can help ensure a smooth and successful transition.

SPEA’s automatic MEMS Test Cells

SPEA’s automatic MEMS test cells offer a valuable solution for manufacturers seeking efficient, reliable, and cost-effective testing capabilities.

By integrating all the necessary components into a single system, SPEA provides a comprehensive and streamlined approach to MEMS testing.

In addition to providing all the elements for the handling, contacting and testing, SPEA MEMS test cells also offer the advantage of a single-manufacturer solution, complete of a user-friendly software environment for the test cell management, and a comprehensive after-sales support for training, troubleshooting, optimization and maintenance.

This integrated approach simplifies the testing process and reduces the complexities associated with managing multiple pieces of equipment from different vendors.

Conclusions

As the MEMS market continues to grow and diversify, companies that adopt standardized test solutions will be well-positioned to meet industry demands, maintain profitability, and drive innovation.

The move towards standardization is not just a trend; it’s a fundamental shift that will enable MEMS manufacturers to achieve greater efficiency, reduce costs, and accelerate the development and production of next-generation MEMS and sensor technologies.
